Family Code:
S HART CFX
Product Code:
S HT-C AB
Plate Size:
Single
Minimum Wall Box Depth:
25mm
Insert Colour:
Black/Black
Plate Material:
Metal
Plate Finish:
Antique Brass
Technical Insert Description:
1 gang 10A Triple Pole Rocker
Current Rating:
10A
CE Marked:
Yes
Max Load:
10 Amp resistive
Voltage:
220/250V AC
Switched Poles:
Triple
Contact Gap Minimum:
3mm
Terminal Capacity 1:
5 x1mm²
Terminal Capacity 2:
4x1.5mm²
Terminal Capacity 3:
1x2.5mm²
Terminal Capacity 4:
1x4mm² Multi-strand
Terminal Capacity 5:
1x6mm²
Earth Terminal Capacity 1:
5x1mm²
Earth Terminal Capacity 2:
4x1.5mm²
Earth Terminal Capacity 3:
3 x2.5mm²
Earth Terminal Capacity 4:
1x4mm² Multi-strand
Earth Terminal Capacity 5:
1x6mm²
Product Class 1:
Must be earthed
Ambient Operating Temperature:
-5° to +40°C
Recommended Location:
Internal Use Only
Max Installation Altitude:
2000m
BS EN ISO Standard:
BS EN 60669-1
Range:
Hartland CFX
Patents:
CFX is a Registered Trade Mark No 2398667Hartland CFX is a Registered Design under Reference Nos.R21 = 3023446 SS2 =3023445
IP Rating:
IP2XD
Mains Frequency:
50Hz
